0.8-2m Ship Marine Salvage Air Bags With Pressure Gauage

Name: 082m Ship Marine Salvage Air Bags With Pressure Gauage
Brand: Jiubei
Price: 1000 USD

Quality 0.8-2m Ship Marine Salvage Air Bags With Pressure Gauage wholesale

Brand Name : Jiubei

Model Number : JB1500

Place of Origin : China

Certification : ISO, SGS

MOQ : 5ton

Price : 1000 usd /pc

Packaging Details : STANDARD SEA WORTHY PACKAGING

Delivery Time : 15days

Payment Terms : tt/lc

Supply Ability : 500pcs per month

Accessories : Pressure gauage

Material : Rubber

Diameter : 0.8-2m

Durability : High

Color : Customized

Installation : Easy

Port : Qingdao

Contact Now

Product Description:

1.Standard size of marine airbags

Diameter(D):0.8~2.0m

Effective Length(EL):6~18m

Total Length(TL):7~19.5m

2 Standard number of layer

In order to confirm airbag's safety working pressure

we define the number of layers,which means the

number of synthetic-tire-cord layers.Normally we

offer marine airbags with 4,5,6,7,8 layers.Other

types are available upon request.

3.Material type of Synthetic-tire-cord

There are two kinds of synthetic-tire-cords with different performance.Refer to following table.

0.8-2m Ship Marine Salvage Air Bags With Pressure Gauage

Features:

D(m)	Mid Pressure(4-5layer)		High Pressure(6-8layer)
	TP(Mpa)	WP(Mpa)	TP(Mpa)	WP(Mpa)
1.0 0.14~0.16		0.12~0.14	0.22~0.260.20~0.24
1.2 1.5	0.12~0.14 0.10~0.12	0.10~0.120.20~0.240.17~0.22 0.08~0.100.15~0.200.13~0.18

Technical Parameters:


Durtarand InnerRubberMaterialParfomanca
Test Item Test Method Required Value
Outer Rubber Inner Rubber
1.Before Ageing
1.1 Tensile Strength ISO37:1994 18 Mpa or more 10 Mpa or more
1.2 Elongation ISO37:1994 400%or more 400%or more
1.3 Hardness ISO 7619:1997 60±10(Shore A) 50±10(Shore A)
2.Afterageing ISO 188:1998 Air oven ageing,70℃±1C96h Air oven ageing,70℃±1C96h
2.1 Tensile Strength 2.2 Elongation 2.3 Hardness		ISO37:1994 ISO37:1994 ISO 7619:1997	≥80%of the oiginal property ≥80%of the original property Not to exceed that original property by more than 8
3.Tear 4.Compression set 5.Static ozone ageing test *A:No cracks after elongation	ISO34-1:1994 400 N/cm or more iSO815:1991 30%(70℃±122h)or less ISO1431-1:1989 *A by 20%and exposure to 50 pphma at 40℃for 96h			No requirement No requirement No requirement
